KuKirin A1

0 kr

Model KuKirin A1 Measurement reference standard（note:unit） Packing info Packing size 1170*250*620mm Packing box size（mm） Product basic parameter Weight Product G.W...

Motor

800W

Battery

48V 800W

Maxed Speed

45km/h

Weight

29.5KG

Max Range

≤45km

Braking System

≤45km

KuKirin A1

0 kr

Description Care

Model			KuKirin A1	Measurement reference standard（note:unit）
Packing info	Packing size		1170250620mm	Packing box size（mm）
Product basic parameter	Weight	Product G.W	29.5±0.5kg	Total weight of product and canton（kg）
	Weight	Product N.W	25.5±0.5kg	Scooter weight（kg）
	Size	Expend size	11545801298mm	LWH（mm）
		Fold size	1154580535mm	LWH（mm）
		Handlebar size	580mm	Diameter（mm）
		Pedal to Handlebar size	510*220mm	L*W（mm）
		Chassis height	990mm	Pedal to highest handlebar distance（mm）
		Pedal size	160mm	No load,height from chassis to ground floor（mm）
	Max Load		120kg	kg
	Speed	Max speed	45km/h	65KG load，Max speed（km/h）
		1st、2nd、3rd（speed limit）	1档：15 、2档：20 、3档：25	Max speed under speed limit mode（km/h)
		1st、2nd、3rd（65kg Load）	1档：20 、2档：30 、3档：45	Max speed of 65KG load（km/h)
	Mileage	Middle speed mileage（65kg Load）	≤45km	Full power,until to stop（km)
	Performance	Climbing ability	≤20° slope	65KG load，Max climbing ability（°）
		Brake system	Front and rear disc brakes + power-off brake	Disc brake, electronic brake, other
		Brake distance	6-8m	Maximum speed braking stopping distance（m）
		Waterproof level	IPX4	IP
	Material	Frame material	Steel Frame
Motor	Motor type		Brushless DC Hub Motor	（Integrated/split/other hub motor)
	Voltage		48V	V
	Acclerate mode		Sine Wave	（Sine wave/square wave/dual modes)
	Power date	Rated power	800W	W
		Instantaneous maximum power	1000W	W
		Rated speed	1100rpm	rpm or r/min
		Max output torque	25N.m	N·m
Battery	Model		18650 Li-battery
	Voltage		48V	V
	Capacity	Single cell capacity	2600mAh	mAh
	Capacity	Battery pack capacity	13Ah	Ah
	Standard power consumption KW.H		0.624kW·h	kW·h
	Battery protect system		BMS
Charger	Input voltage		100~240V/50~60Hz	VAC
	Input current		2.5A	A
	Output voltage		54.6V	VDC
	Output current		2A	A
	Charging time		7-8h	h
Shock absorber system	Front shock absorber		Glue filling shock absorption	（Spring shock absorption/Hydraulic damping shock absorption/other)
Shock absorber system	Rear shock absorber		Glue filling shock absorption	（Spring shock absorption/Hydraulic damping shock absorption/other)
Light System	Headlight type		LED	Light source
	Headlight power		1.7W	W
	Headlight illumination angle		adjustable	Illumination angle width（°）
	Headlight irradiation area		6㎡	The maximum area of normal projection onto the ground（㎡）
	Turn light		Yes
	Taillight		Yes（Steady light, high light when braking）
Tire	Size		10in	Out tire size（ in） Note：1 in = 25.4 mm
	Type		Vacuum tire	Off road/Honeycomb/Vacuum/Pneumatic tire：（Road tires, off-road tires）
	Optimum tire pressure		330-360kPa (48-53psi）	kPa/psi
Disc brake disc	Outer diameter		140mm	Diameter（mm）
Disc brake disc	Thread hole diameter		M6	（mm）
Instrument	Type		LED	LED/LCD/OLED
	Instrument material		Instrument case ABS
	Size		80*50mm	L*W（mm）
	Show content		Speed, battery level, cruise control, speed mode, start mode, headlight icon, mileage unit mode, etc.	Please refer to the instrument manual for details.
	Function setting		（1）Button: Insert the key into the ignition switch hole, turn the key clockwise to the start position, and then press and hold the power button to turn on the device. After turning on the device, short press the power button once to adjust the gear position. Short press three times in a row to enter the menu setting interface, and long press to turn off the device. Light button: Short press to switch the instrument display data, and long press to turn on the headlights, LOGO, and taillights. （2）Menu settings: After short pressing the power button three times in a row to enter the menu settings interface, the instrument will display P1, P5, P6, P8, PA, PB, and PC, which respectively represent: P1 for kilometer/mile selection setting; P5 for cruise and no cruise selection setting; P6 for non-zero start and zero start selection setting; P8 for automatic sleep time setting; PA for starting force setting; PB for braking force setting; PC for total mileage clearing setting. （3）Speed limit mode setting: Squeeze the brake lever and double-click the power button at the same time to enter speed limit mode.	Please refer to the instrument manual for details.
Packing list			Charger1, Instruction manual1, Allen wrench2, Pole screws4, Desiccant2, Key2	without electric scooter
